How to Measure for Pre-Fab Cabinets: A Step-by-Step Guide

Installing pre-fabricated cabinets is a cost-effective, stylish way to upgrade your kitchen, bathroom, or office—but before you can enjoy the transformation, it all starts with accurate measurements. Getting it right the first time saves you time, money, and frustration.

Follow this step-by-step guide from the cabinet pros at Six Points Cabinets in Phoenix to measure your space like a professional.

Step 1: Gather the Right Tools

Before you begin, make sure you have:

A steel measuring tape (not a cloth one)
Graph paper or a printable cabinet layout sheet
Pencil and eraser
Step stool (for upper cabinets)
Level (optional, but helpful)
Camera or phone (for reference photos)

Step 2: Measure the Overall Room

Start by measuring the total length of each wall where cabinets will be installed:

Measure from corner to corner, wall to wall.
Record the ceiling height.
Note any obstructions like soffits, bulkheads, or uneven flooring.

Pro Tip: Always measure in inches and double-check your work.

Step 3: Mark Key Features

Measure and mark the location of:

Doors and windows (include height, width, and distance from the floor and corners)
Electrical outlets and switches
Plumbing connections and gas lines
Appliances (fridge, oven, dishwasher) and their required clearances
Vents, air returns, or other permanent fixtures

Take pictures of these areas for easy reference later.

Step 4: Find Your Centerlines

If you’re installing a sink base cabinet, dishwasher, or cooktop, you’ll need to measure the centerline (the distance from one wall to the center of the fixture or connection). This helps align pre-fab cabinets accurately.

Step 5: Measure Wall Heights and Ceiling Variations

Especially in older Phoenix homes, ceilings aren’t always perfectly level. Measure the wall height in at least three different spots to ensure consistency.

If the ceiling height varies, go with the shortest height when planning cabinet sizes.

Step 6: Sketch Your Layout

Using graph paper, sketch a simple floor plan with all your notes, including:

Wall lengths
Window/door locations
Appliance locations
Plumbing and electrical features

Label each wall (e.g., Wall A, Wall B) and include all dimensions.

Step 7: Double Check and Consult the Experts

Even a 1-inch error can throw off your entire installation. Double-check all measurements, then reach out to our cabinet team to review your layout and ensure the pre-fab sizes you select will fit seamlessly.

Why Measure Carefully for Pre-Fab Cabinets?

Pre-fabricated cabinets come in standard sizes, which means your measurements need to be precise to avoid gaps, overlap, or the need for excessive fillers. When done right, the result is a polished, built-in look that adds value and style.
